26 INCH ALLOY FRAME FAT/SNOW BIKE ON ROAD

Categories	Fat Bike
Brand	Ocean Bicycle
Model	OC-26/20-4.0
Frame	Aluminum 6061
Fork	sus fork w/alloy crown
Derailleur	24S
Brake	Dau-disc-brake
Rim	26*4.0 alloy hollow rim
Package	85%SKD/CKD
Unit Price	US $ 190-202 / set
FOB port	Xingang Tianjin
Terms of Payment	L/C, T/T
Download DOC
Update Time	June 10,2023

Contact Now

Detail Information

Fat bike on road

Specifications:

FRAME
Sizes	S, M, L, XL
Colors	red/black logo
Frame	alloy head tube：4451120MM
Fork	26"sus adjustable，34，disc-brake，stand tube：Φ28.6Φ25.4200Lno thread
Shock	N/A

COMPONENTS
Handlebar	Ocean model, swallow alloy 580W hold distance 180MM 2.2T
Stem	Ocean model,alloy 28.6*31.8mm EXT;100MM 2.2T
Seatpost	Ocean sport, alloy 30.4*350L
Saddle	Ocean Connect,black
Pedals	9/16″alloy with ball

DRIVETRAIN
Shifters	Shimano RS-65 8 speed
Front Derailleur	Shimano M310 34.9 pull push
Rear Derailleur	Shimano M310 8S
Brakes	Huihong alloy mechanical disc 160mm
Brake Levers	Shimano alloy 3 finger
Cassette	Shimano HG-41-8 8PCS
Chain	KMC-Z72 3/32"*110L
Crankset	Prowheel alloy 1/23/3224T34T42T9/16170mm
Bottom Bracket	once piece sealed 167L

WHEELSETS
RIM:264.014G36H A/V ALLOY HOLLOW*

Hubs	KT alloy F:14G36H135W145L M9 QR R:14G36H190W200L D;39MM QR

OTHER

Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All Giant bikes are designed for best-in-class weight and ride quality.
